Chinaproductionofceramicedgegrinding45degreeschamferpolishingmachine,fromfoshanyongtaomachinery,professionalsalesofceramicedgegrindingmachine,ceramicchamferingmachine,ceramicpolishingmachineandotherceramicprocessingmachinery,manufacturersprovideceramicedgegrinding45degreeschamferingmachineprice,welcomeinquiry。
YTMDP-1200 type 2+3+10 ceramic edge grinding 45 degrees chamfer polishing machine
Parameter:
(1) Conveyor belt: 350mm
(2) Nos. of squaring head: 1pc
(3) Diameter of squaring wheel:Φ200mm
(4) Power of squaring head: 3kw
(5) Nos. of 45 degree chamfering head: 3 pc
(6) Power of chamfering motor: 2.2kw *3
(7) Diameter of chamfering wheel: Φ200mm
(8) Nos. of polishing head: 8 pc
(9) Power of polishing head: 1.5kw *4
(10) workable width: 100-1000mm
(11) Power of conveyor belt: 2.2kw
(12) Conveyor speed: 4-20m/min
(13) Thickness of tile: 6-20mm
(14) Total power: 17.8kw
(15) Air consumption: 50L/min
(16) Water consumption: 320/min
(17) Dimension of machine: 4.6m*2.0m*1.5m
(18) Weight: about 4T
YTMDP-1200 type 2+3+10 ceramic edge grinding 45 degrees chamfer polishing machine
Parameter:
(1) Conveyor belt: 350mm
(2) Nos. of squaring head: 1pc
(3) Diameter of squaring wheel:Φ200mm
(4) Power of squaring head: 3kw
(5) Nos. of 45 degree chamfering head: 3 pc
(6) Power of chamfering motor: 2.2kw *3
(7) Diameter of chamfering wheel: Φ200mm
(8) Nos. of polishing head: 8 pc
(9) Power of polishing head: 1.5kw *4
(10) workable width: 100-1000mm
(11) Power of conveyor belt: 2.2kw
(12) Conveyor speed: 4-20m/min
(13) Thickness of tile: 6-20mm
(14) Total power: 17.8kw
(15) Air consumption: 50L/min
(16) Water consumption: 320/min
(17) Dimension of machine: 4.6m*2.0m*1.5m
(18) Weight: about 4T
